Rubber and plastic low temperature brittleness testing machine HZ-7004

Equipment Overview

Rubber Low Temperature Brittleness tester is used to measure the highest temperature when vulcanized rubber is impacted to damage under special condition, and the temperature is called brittle temperature. It is used to identify the different usability between non-rigid plastic and other flexible materials under low temperature conditions. It also can measure the brittle temperature and low temperature performance quality of different kinds of materials or different formula vulcanized rubber, so it is indispensable for scientific research materials,quality inspection and production control etc.



StandardLGB1682-82 design, the technical indicators in line with national standards.



Applicable Industry:Rubber Industry.



Technical Parameters

Model

HZ-7004

Standard

GB1682-82

Test temperature

-40 Centigrade--0cCentigrade

Impact speed

2m/s ±0.2m/s

temperature fluctuation

<±0.5Centigrade

distance between the center of impactor

to the bottom of gripper

11±0.5mm

Outside size

720mm*700mm*1380mm

Power

1100W

Cold well volume

700ml
