Wire Industry Digital Touch Screen 2 TON Terminal Tensile Testing Machine Equipment HZ-1010-Dongguan Lixian Instrument Scientific Co.

Product Details

Equipment summary:
Wire Industry Digital Touch Screen 2 TON Terminal Tensile Testing Machine Equipment can be tested the constant-velocity loading, constant- velocity displacement. Floor-standing models, it is taken account of modern industrial design and ergonomics in modeling and coating. Terminal tensile strength testing machine is designed by mechanical-electrical integration, composition of the force-measuring sensor, transmitter, microprocessor, mechanism of load drive , computer and color inkjet printer. it has accurate load speed,range of force measurement, Has high accuracy and sensitivity for the load, displacement measurement and control, it also can be tested the constant-velocity loading, constant- velocity displacement. Floor-standing models, it is taken account of modern industrial design.

Specification

Model Number	1010A
Certification	ISO/ASTM/CE
Maximum load	2 ton
accuracy of load measurement	the load cell + HZ-2000 screen ± 0.5%(full range of 5% -100%)
Resolution	1 / 50000
displacement resolution	0.001mm
power system	AC motor,deceleration device(fromItaly)
displacement	400, 500, 600mm (or customize)
Range of testing speed	50~300 mm/min
Accruacy of displacement measurement	Tolerance: ±0.5%/ tolerance: ±0.2%
Data sampling frequency	200 times/sec

More machine types


HZ-1007A	HZ-1007C	HZ-1007E	HZ-1003E	HZ-1005B	HZ-1005A
Max Force:200kg	Max Force:200kg	Max Force:100kg	Max Force:500kg	Max Force:500kg	Max Force:500kg

HZ-1003A	HZ-1004A	HZ-1009A	HZ-1010A	HZ-1009C	HZ-1009B
Max Force:3T	Max Force:500kg	Max Force:10T	Max Force:3T	Max Force:10T	Max Force:30T
