- Product Details
Product summary：
Applied to test the moisture permeability character of plastic film, composite film and other packaging materials, and a variety of material in the health care field . Through the determination of moisture vapor transmission quantity, to control and adjust specifications of the material, to meet the needs of product application.
Meet standard:
ASTM E96、ASTM D1653、TAPPI T464、ISO 2528、DIN 53122-1、JIS Z0208
Technical parameters:
| Model: | HZ-1905 |
| Measurement range: | 0.1～10，000g/m2·24h |
| Sample number: | 1～12 PCS |
| Test accuracy: | 0.01g/m2·24h |
| System resolution: | 0.0001g |
| Temperature control range: | room temperature～50℃ |
| Humidity control range： | ±0.5℃ |
| Test humidity： | 40%RH～90%RH(standard 90%RH) |
| Humidity control resolution: | ±1%RH |
| Test area： | 33cm2 |
| Sample thickness: | ≤3mm |
| Sample size: | Φ74mm |
| Power: | AC 220V 50Hz |
| Dimension of frame: | 826(L)mm×726(B)mm×670(H)mm |
| Toal weigh: | 114kg |
Product feature：
·Weighing principle, high testing efficiency
·Twelve samples testing at the same time or test combination (equivalent to 12 chamber test)
·Meet different test conditions set and automatic control.
·Penetration and weighing in same environment, artificial operation small error.
·High precision sensor, the test data is accurate and reliable.
·Flexible heater, professional design, heating even
·Test temperature P.I.D. accurate control
·Professional software support, test data dynamic display, visual in image
·Open test data storage, be helpful for quality dynamic analysis
·With the function of data storage, inquiry, printing, drawing, communication perfect.
·The computer automatic monitoring the whole process, system stability, simple operation, and friendly human-machine interaction
·Before testing set the parameters, temperature, humidity and test interval, etc
